Diesel Generator Power Source
It uses diesel as fuel and drives the generator to output power through an internal combustion engine. It is suitable for field or mobile operation scenarios without external power supply and has independent power supply capability.
Working Principle and System ProcessThe power source (electric motor / diesel generator) drives the high-pressure piston pump to operate through a coupling; the high-pressure piston pump sucks hydraulic oil from the hydraulic oil tank, pressurizes it, and outputs high-pressure oil; the high-pressure oil flows through the directional valve, relief valve, and unloading valve in sequence through pipelines, and is finally delivered to the hydraulic motor of the actuator (hydraulic hole opener / hydraulic plugging cylinder) through hydraulic oil pipes; after the actuator completes the operation, the oil flows back to the tank through the return pipeline or internal leakage channel, forming a closed-loop circulation system.
